Automatic PET Bottle Filling Machine / Bottling Line / Project

Stroj "tri u jednom" za PET bocu integrira funkciju ispiranja, punjenja i zatvaranja zajedno. Zasnovana na naprednoj inozemnoj tehnologiji i dizajnirana prema zahtjevima za obradu vode za punjenje

Glavne značajke

1. This machine has a compact structure, completed control system, easy to operate and highly automated.

2. By changing the star-wheel, screw bottle inlet and arc guide plate can realize to change the bottle shape.

3. The parts that direct contact with product are made of food grade stainless steel and no technology corner pockets and easy to clean.

4. By adopting high speed filling valve, the liquid level is precise and no waste. That guarantees the demand of filling technology.

5. The machine adopts high effective cap sorting system and completely self control and protective device.

6. The machine is equipped with perfect overload protective device that can keep the equipment and operator safely.

7. The control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.

8. The electric components and pneumatic components are all introduced from world famous brand products.

Iznos radne pozicije	Ispiranje 32, punjenje 32, zatvaranje 10
Kapacitet proizvodnje	15000BPH (500 ml)
Tlak izvora zraka	0.7Mpa
Potrošnja zraka	1.2m3 / min
Tlak vode za ispiranje	0.2-0.25Mpa
Kapacitet vode za ispiranje	2.5T / H
Glavna snaga motora	3.2kW
Ukupna snaga	4.8kw
Dimenzija	4250X2150X2200 mm (D × Š × V)
težina	5200kg

Također nudimo i Postrojenje za automatsko flaširanje čiste vode

Sadrži 4 glavna dijela:

1. Plastic bottle blow molding machine
2. Water cleaning system
3. Water washing, filling, capping machine.
4. Conveyor system, labeling machine, dating machine, film wrapping machine

Glavni opis cjelokupnog retka:

1. The plant can produce different volume bottles, from 200ml to 2000ml bottles, round and square bottles, plastic and glass bottles. It is very easy to change the different bottle molds.

2. The plant is highly automatic, you can operate on the touch screen to adjust the machine speed and working.

3. We have different speed plants, commonly, 2000BPH, 4000BPH, 7000BPH, 10,000BPH, 15000BPH..ect.

4. The material is stainless steel 304, food grade much clean and safe.

5. We provide the engineers for customer installation, training in customer's factory.

Modeli i popis brzina

Model	XGF8-8-3	XGF14 / 12/5	XGF16 / 16/5	XGF24 / 24/8	XGF32 / 32/10
Pranje ruku	8	14	16	24	32
Ventili za punjenje	8	12	16	24	32
Hvatanje ruku	3	5	5	8	10
Prikladne boce od PET / stakla (150ml do 2000ml)
Kapacitet (brzina) Baza na 500ml	2000BPH	5000BPH	7000BPH	12000BPH	15000BPH

Dobavljač robnih marki električnih komponenata

Glavni sastav	Opis dobavljač
PLC	Mitsubishi (Japan), Siemens (Njemačka)
Ekran na dodir	Weinview (Taiwan)
Pretvarać frekvencije	Mitsubishi (Japan), Siemens (Njemačka)
Zračna sklopka	Schneider (Francuska)
Prekidač	Siemens (Njemačka)
dobavljač	Siemens (Njemačka)
Fotoelektrična sklopka	Omron (Japan)

Brzi detalji

Vrsta: Stroj za punjenje
Stanje: Novo
Primjena: pića, kemijska, medicinska
Vrsta ambalaže: Boce
Materijal za pakiranje: plastika
Automatski stupanj: Automatski
Vrsta pogona: Električno
Napon: 380V / 220V
Snaga: 4,8KW
Mjesto podrijetla: Šangaj, Kina (kopno)
Naziv marke: VKPAK
Dimenzija (D * Š * V): 4250X2150X2200 mm
Težina: 5200KGS
Certifikacija: CE, ISO, SGS
Dostavna usluga: Inženjeri dostupni za servisiranje strojeva u inozemstvu
Tvornica: STROJNI STROJI
Veličina boce: 150ml do 2000ml
Promjer vrata boce: 15-55mm
Materijal za boce: plastika / staklo
Brzina (baza na bočici od 500 ml): 15000B / h
Upravljački sustav: PLC zaslon osjetljiv na dodir (MITSUBISHI JAPAN)
Cap: vijak / pritisnite poklopac
Dizalo kape: Imati
Tekućina za punjenje: mineralna / čista voda
